Cylinder boring machine T8014A (220V)

Cylinder boring machine T8014A (220V)

Attention

1.Check whether the upper plane of the cylinder body is clean and straight .

2.If the discovery is unequal, it should be leveled in order to Keep good touch with the bottom of the cylinder boring machine and verticality of Cylinder wall and Cylinder block.

Specification

voltage	220V
Frequency	60Hz
Model	T8014A
Boring Range:	φ2.5991-5.5118inch(65-140mm)
Max boring Depth	11.81inch(300mm)
No of single speeds	250r/min
Feed	0.0046inch(0.11mm)/rev
Quick -Return	0.4173inch(10.6mm)/sec
Out -put	0.25kw
Motor speed	1720r/min
Type:	induction fully enclosed
Centing Fingers (Diameter)	2.5590-3.0709inch(65-78MM)
	3.0709-3.5827inch(78-91MM)
	3.5827-4.0945inch(91-104MM)
	4.0945-4.6063inch(104-117MM)
	4.6063-5.1181inch(117-130MM)
	5.1181-5.5512inch(130-141MM)
Over Dimension (LWH)	12.61333inch(323385CM)
Packing	Wooden box packing
Packing Size	16.715.941.5 inch
Shipping Weight	188lb

http://topseller365.com/data/prd/022/781/9.jpg

Item Number: 022781

You can make order with no worry.
Any concerns just feel free to let us know, we'll reply in 24 hours in normal condition.
Handling Time: Shipping is usually made in 1-3 business days after payments cleared. Orders are processed from Monday-Friday; Not on the weekends & public holidays.
Warranty: 6 months' warranty for the machines, not for the consumables.
We stand behind our products all the item, so even if your warranty period has expired, you can still seek for service or technical support from us with low cost.
