Product Overview
110V Portable Auto Gas Welding Machine Carriage Welding Trolley
for Alloy Welding Machine Steel Structure 150-900MM/MIN
 |
| This welding machine is fully
automated, equipped with a simple control panel and rubber drive
wheels to make welding more stable and safe.
The machine is small in size,
light in weight, easy to move and install. Suitable for a
variety of occasions, such as chemical, mechanical, petroleum,
electricity, construction, mining industries, etc. |
| Model: |
HK-8SS |
| Voltage: |
AC110V |
| Power: |
22W |
| Welding
speed: |
5.91-35.43"/min
(150-900mm/min) |
|
Adsorbability: |
110LBS(50Kg) |
| Range of
working angle: |
±45° |
| Range of
adjusting angle: |
±10° |
| Range of
working angle: |
360° |
| Range of
adjusting welding torch (Up, down, left and right): |
1.97" (50mm) |
| Driving
mode: |
Rubber wheel four-wheel
drive |
| Package size: |
20.47"*13.39"*13.39" (52cm*34cm*34cm) |
| Net weight/Gross weight: |
24.25LB(11kg)/28.22LB(12.8kg) |
| Product Features & Advantages |
 |
1. Torch
Adjusting Handle:
The operation accuracy is
high, there is almost no error, and the welding work can
be completed perfectly.
A: Torch adjusting handle
B: Upper and lower
adjusting handle
C: Left and right
adjusting handle
D: Adjustable 360°
|
2. Work
Efficiently:
HK-8SS is a professional
auto welding carriage, it can reduce work intensity and
improve working conditions. Compare with manual welding,
it can increase the working efficiency, it is
lightweight and easy to operation, can do better by it
than a technical worker using a normal welding machine.
A: Red aluminum handle for
easy carrying
B: Scale for precise
adjustment of the length of the guide bar
|
 |
 |
3. High
Precision Guide Wheel Assembly:
The machine is equipped with a retractable guide assembly on
the side of the machine, when in use, you only need to
extend the length of the front side guide bar slightly
shorter than the rear side guide bar, forming an angle of 15
degrees.
|
4. Thickened
Rubber Wheels:
It is designed with high-temperature resistant rubber
wheels, and the four-wheel drive mode allows the trolley to
walk with a high degree of smoothness, and at the same time,
the welding is not easy to stick.
|
 |
 |
5. Torch
Interface/
Electrical Box Interface:
Comes with 5 meters welding torch control line, independent
power control box, welding torch can be directly connected,
easy to move, safe and reliable.
|
6. Portable
Handle Design:
This welding machine is equipped with a portable handle,
comfortable grip, making it easy for one person to carry and
move the machine.
|
 |
Features:
1. The machine is small in size,
light in weight, easy to move and install.
2. The trolley adopts imitation dust and has a long service
life.
3. Adopt four-wheel drive, high temperature resistance, stable
welding and walking.
4. The gear rotation method is adopted to avoid the loose gap in
the traditional chain transmission method and the phenomenon of
shaking when walking.
5. Vertical fillet welding and horizontal fillet welding are
possible.
|
| Product Presentation & Details |
|
Auto Welding Trolley
*1 |
Power Control
Box *1 |
Signal Connection Cable *2 |
|
Hex Wrench Set *1 |
English Manual *1 |
|
|
You can
make order with no worry.
Any concern just feel free to let us know, we'll reply in 24
hours in normal condition.
Handling Time: Shipping is usually made in 1-3 business days
after payments cleared. Orders are processed from Monday-Friday;
Not on the weekends & public holidays.
Warranty: 6 months' warranty for the machines, not for the
consumables.
We stand behind our products all the item, so even if your
warranty period has expired, you can still seek for service or
technical support from us with low cost. |
|
